Wireless ceiling smart infrared detector SL-801W

Features:This is a ceiling-mounted smart wireless passive infrared detector for

  • Commodity name: Wireless ceiling smart infrared detector SL-801W
  • Product Details
  • Features:

    This is a ceiling-mounted smart wireless passive infrared detector for indoor applications. It consists of a dual-element passive infrared sensor and advanced

    Micropower processing circuit technology. It has very low missed alarms and false alarms, and uses bidirectional temperature compensation technology to operate over a wide temperature range.

    Complete intrusion motion detection within the range. It also adopts a unique pet variable calculation method and has a pet-proof level of up to 10 kg. In addition, heat resistance

    It also performs well in detecting false moving objects such as airflow and curtain swings, and can provide stable detection at two sensitivity levels.

    Power consumption design, the battery can be used for more than two years, and other performance and stability far exceed that of ceiling-mounted models of the same price on the market

    Infrared Detectors.



    Specifications:

    Power supply: 2 1.5V batteries, battery size AA

    Current consumption: 20uA (standby) 14mA

    Installation height: 2.4m-3.6m

    Detection range: φ8m 360°

    Temperature compensation: intelligent digital compensation technology

    Pulse: 2 pulse/3 pulse selection

    Sensitivity: high and low sensitivity selection

    Anti-electromagnetic interference: 0.1-500MHz/30V/m

    Anti-white light interference: >10000LUX

    Alarm data: EV1527/PT2262 encoding format

    Alarm time: 2s

    Alarm cycle: 4 minutes (working mode)

    Wireless transmission distance: greater than 200m (open space)

    Wireless transmission frequency: 315MHz or 433MHz

    Working temperature: -10℃/+55℃

    Detection speed: 0.2m/s-3.5m/s

    Fire protection: ABS engineering plastic

    Anti-pet weight: 10KG

    Volume: diameter 115*32mm
